HX Series Vibrating Screen

01Processing capacity:75-900t/h
02Max Feeding Size:200-400mm
03Processing Material:200+ kinds

Processing Material: sandstone, pebble, limestone, granite, quartz, iron ore, copper ore, gold ore, basalt, etc.

Send Enquiry Get Quotation(contact us by one of the three ways)

If you are interested in our products, please email us at sinohxjq@hxjq.com

Introduction of HX Series Vibrating Screen

HX series vibrating screen is a kind of new vibrating screen produced by our company. It is upgraded and improved according to the customers’ feedback and maintenance experience.

It is widely used for screening gravel, rock ,sand, aggregate and other stones and ores in stone crushing line, sand making production line, mobile crushing plants and ore beneficiation plant.

Features of HX Series Vibrating Screen

With screen angle of 18°, it has higher screening efficiency. Thin oil self-lubrication, replace the oil once every 3-6 months. A wear-resistant rubber protective layer has been used at key parts to extend the service life of the screen.

Due to its high performance and 100% factory price, our vibrating screen has been exported to over 90 countries such as Indonesia, Malaysia, Kenya, Tanzania, Ethiopia, Nigeria, South Africa, Egypt,etc. If you are new in this industry, we will provide professional suggestions and solutions for you.

Advantages of HX Series Vibrating Screen

Three large sized workshops, strict quality control system and decades of years production technology make our crusher machine better performance, higher crushing efficiency and longer service life.

01
Strong Vibrating Force

Unique vibration way, full models for choice
02
Easy Operation & Maintenance

Compact structure, reliable performance
03
Long Service Life

High quality mesh,less quick-wear parts
04
Energy Saving,Low Costs

Low power consumption, high efficiency

Technical Data of HX Series Vibrating Screen

Model	Sieve Layer	Sieve Obliquity (°)	Motor Power (kw)	Vibrating Frequency (r/min)	Max.Feeding Size (mm)	Capacity (t/h)	Dimensions(mm) （L×W×H）
2HX1545	2	18	15	780-900	200	45-500	5380×2295×1410
3HX1545	3	18	18.5	780-900	200	55-500	5575×2295×1990
4HX1545	4	18-20	22	780-900	200	65-500	5765×2295×1990
2HX1855	2	18	18.5	780-900	200	55-600	5680×2565×1450
3HX1855	3	18	22	780-900	200	65-600	5900×2565×2110
4HX1855	4	18-23	22	780-900	200	75-600	6030×2565×2500
2HX2165	2	18	30	780-900	200	65-700	7160×2990×1690
3HX2165	3	18	30	780-900	200	75-700	7380×2990×2365
4HX2165	4	18-23	37	780-900	200	85-700	7430×2990×2500
2HX2465	2	18	37	780-900	200	80-800	7160×3290×1690
3HX2465	3	18	37	780-900	200	90-800	7380×3290×2365
4HX2465	4	18-23	37	780-900	200	100-800	7430×3290×2500
2HX2765	2	18	37	780-900	200	100-900	7180×3570×1805
3HX2765	3	18	45	780-900	200	110-900	7390×3570×2445
4HX2765	4	18-23	45	780-900	200	120-900	7480×3570×2715
2HX3065	2	18	37	780-900	200	110-1200	7180×3870×1805
3HX3065	3	18	45	780-900	200	120-1200	7390×3870×2445
4HX3065	4	18-23	45	780-900	200	130-1200	7480×3870×2715
2HX3075	2	18	22×2	780-900	300	120-1300	8700×4055×1980
3HX3075	3	18	37×2	780-900	300	130-1300	8940×4120×2720

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
